Forced Convection Oven SH-DO-100FGB | SH Scientific Korea
Basic Model
– With TurboFan and ON/OFF function.
– Internal observation is possible through the viewing window
– Stainless Steel Internal Chamber with shelves
– Excellent temperature uniformity and accuracy
Technical Specifications:
| Model | SH-DO-100FGB |
| Air Circulation type | Forced |
| Temp Range | Ambient +10℃ to 250℃ (Ambient +18℉ to 482℉) |
| Temp&Time controller | Microprocess PID controller |
| Heater Capacity | 1600 W |
| Dimension Internal (W×D×H) | 480×400×530mm 18.90×15.75×20.87” |
| Dimension External (W×D×H) | 635x570x905mm 25.00×22.44×35.63” |
| Weight | 50 kg |
| Capacity | 100 L |
| Material Internal | Stainless Steel |
| Material External | Steel Plate With Powder Heating Coated |
| Shelves | 2 Supplied (12 Maximum) |
| Fan Position | Bottom |
| Electrical Requirements 120V ,50/60Hz, 1Φ | 14.5 A |
| Cat. No. | DO100FGB120 |
| Electrical Requirements 230V,50/60Hz, 1Φ | 7.0 A |
| Cat. No. | DO100FGB230 |
• Accessory
-Movable stainless wire shelves 2EA
• Safety Device
-Automatic reset function incoming power cut
-Buzzer on when set time arrived
-Door open alarm
-Over temp function
-Feature
Forced Convection Oven is commonly used in laboratories and other related industries for the purpose of sample drying and sterilization. It also comes with outstanding features such as high level of temp. uniformity, precise accuracy and stable temperature control. All of these are possible through our advanced technology and continuous innovation.
— Digital PID controller
– Surface finished stainless steel
– Powder coated steel plate
– Leveling feet
– Safety devices
– User friendly door handle
